ECDIS DM-800

SOLAS-compliant Electronic Chart Display and Information System featuring dual-chart engine and innovative SWAP technology.

[ DANELEC ]Navigation

[ PRODUCT OVERVIEW ]

The Danelec ECDIS DM-800 is a fully type-approved Electronic Chart Display and Information System. Engineered to meet the strict IMO carriage requirements, it features a dual-chart engine that displays official S-57/S-63 ENC, C-MAP, and AVCS charts side-by-side. It serves as a direct, paperless navigation replacement under SOLAS mandates.

The DM-800 incorporates Danelec's unique SWAP (Shared Wear-out Parts) technology, which stores system configuration and licenses on a hot-swappable module, enabling rapid on-board servicing and backup preservation. Operating on a secure fanless Linux OS, it minimizes the risk of viruses and malware.

[ TECHNICAL SPECIFICATIONS ]

Display Support	19-inch, 24-inch, or 27-inch widescreen color LCD monitors
Input Controls	ECDIS Keyboard and integrated high-precision trackball
Processor Unit	Linux-based fanless marine computer unit
Serial Channels	12 serial ports (10 x IEC 61162-1, 2 x IEC 61162-2)
Network Interface	4 x RJ45 ports (100BASE-TX Ethernet)
Power Source	110-230V AC, 50-60Hz with automatic UPS fallback

SYS.STATUS: OPERATIONAL

IACS // EGY-HQ

CHART ENGINE:S-57 / S-63 DUAL

SYS COMPLIANCE:IEC 61174 ED.4

SAFETY DEPTH:10.0M SET

AIS TARGETS:250 ENCODED

[ KEY FEATURES ]

SOLAS Dual-Redundant Chart Engine supporting ENC, C-MAP, and AVCS
Danelec SWAP technology for easy servicing and hardware swaps in under 10 minutes
Stable, secure fanless Linux operating system to prevent malware infections
Intuitive user interface with day, dusk, and night navigation display layouts
10-year hardware and service availability guarantee from Danelec Marine
